Optional i-Modules* |
|
|
Part Number |
Description |
|
MIC-75M40 (Q370) |
4-slot expansion module (4 x PCIe slots) |
|
MIC-75M13 |
4-slot expansion module (1 x PCIe and 3 x PCI slots) |
|
MIC-75M20 |
2-slot expansion module (2 x PCIe slots) |
|
MIC-75M20-01 (Q370) |
2-slot expansion module (2 x PCIe slots) |
|
MIC-75M11 |
2-slot expansion module (1 x PCIe and 1 x PCI slots) |
|
MIC-75M10 |
1-slot expansion module (1 x PCIe) |
|
MIC-75G20 |
GPU Card expansion module (2 x PCIe and 2 x removable 2.5" storage bay) |
|
MIC-75S20 |
2-slot expansion and storage module (2 x P |
|
*Please refer to i-Module datasheet for more detail. |
|
Optional Accessories |
|
|
Part Number |
Description |
|
96PSA-A220W24P4-1* |
Adaptor A/D, 100-240V, 220W, 24V |
|
96PSA-A150W19P4-1** |
Adaptor A/D, 100-240V, 150W, 19V |
|
1702002600 |
Power cord (USA) UL/CSA, 3-pin, 10A, 125V, 1.83 M, 180 D |
|
1700022940-01 |
Power cord PSE, 3-pin, 7A, 125 V, 3M, DAC-ST01 |
|
1702002605 |
Power Cord (EU), 3-pin, 10A, 250V 1.83M, 90D |
|
PCA-TPM-00B1E |
TPM 2.0 module |
|
98R1750000E |
MIC DVI kit FIO |
|
98R1750030E |
MIC HDMI kit FIO |
|
98R1750060E |
MIC COMport kit FIO |
|
98R1750070E |
MIC Remote Switch kit for SFIO |
|
98R1750080E |
MIC Reset/Remote Switch/5VDC kit FIO |
|
98R1750090E |
MIC GPIO kit |
|
98R1750020E |
MIC Din Rail Mounting kit |
|
98R1750050E |
MIC Wall Mounting kit |
|
Note: |
|
|
*Suggest to use for MIC-770 with i-Module added. |
|
* Suggest to use for MIC-770 without i-Module added. |
|
1. MIC-770 supports Advantech iDoor modules (both MOS and PCM series), excluding the PoE model. |
|
2. The PCM series module requires a bracket (P/N: 1960065854N001) that must be ordered separately. |
|
Embedded OS |
|
|
Part Number |
Description |
|
20706WX9HS0005 |
img MIC-770H Win10 IOT Enterprise 2019 LTSC 64b high end |
|
20706WX9VS0007 |
img MIC-770H Win10 IOT Enterprise 2019 LTSC 64b value |
|
20706WX9ES0010 |
img MIC-770H Win10 IOT Enterprise 2019 LTSC 64b entry |
|
20706WX9HS0004 |
img MIC-770Q Win10 IOT Enterprise 2019 LTSC 64b high end |
|
20706WX9VS0006 |
img MIC-770Q Win10 IOT Enterprise 2019 LTSC 64b value |
|
20706WX9ES0009 |
img MIC-770Q Win10 IOT Enterprise 2019 LTSC 64b entry |
